1746-HT 1746HT AB AB Termination Panel
⇒ Click here for good price 1746-HT
| Brand/Manufacturer | AB/USA |
| Part Number | 1746-HT |
| Alternate Part Number | 1746-HT |
| Description | MOTOR SERVO |
| Dimennsions | 32x8.7x8.8cm |
| Weight | 0.4kg |
Contact Us
Email: miya@mvme.cn (CLICK)
QQ: 2851195450
Tel: 86-18020776792(CLICK)
Skype:miyazheng520(CLICK)
Product Details
The AB 1746-HT is a termination panel. The panel comes with a 292
mm (11.25 in.) height and a 70 mm (2.75 in.) width. The panel
provides flexibility to the SLC servo control system. The 1746-HT
panel features an E-stop connection for the E-stop ring. Fast I/O
connection for the three inputs, one output, and the LED show the
status for each I/O point. When there is an encoder, there should
be encoder feedback for one axis. All drive connections are
directed to the analog drive. The 1746-HT panel provides external
connections for +5, +15, and +24 V power from the power supply. The
panel is mounted on the DIN rail and it can be mounted up to 2.1 m
(7 ft) from the motion control module with just a screwdriver and a
wire stripper.
The 1746-HT termination panel consists of a drive within a drive,
Drive Return, and a Shield. The Panel's encoder has Channel A
Hi/Low, an AB Shield, Channel B Hi/Low, a Z Shield and Channel Z
Hi/Low. The Encoder power has a +5 V node, Return, +15 V node and a
Shield. The Exit power of the panel consist of +5 V, Return, +15 V,
-/+ Return, -15 V, +24 V, +24 V Return and a EGND. It has an axis
that can be linear or rotary. The 1746-HT has a drive enable and
ESTOP that consists of +24 V, 2 RES. PB, RESET, STRING IN/OUT. The
panel has a FAST I/O that consists of FAST IN. 1, +24 V, FAST IN.
2, +24 V, FAST IN. 3, Return, FAST Output. 1 functions.
Why choose us
1. We will provie you the product info and picuture
2.Large stock, fast delivery
3.Competitive prices and immdiate quotation
4.Professional service,professional technical support
5. Warranty time is one year.
6. Strict test machine before shipment.
7. We could help you to get any components which is difficult to
get
